| Brand Name : | SONTUOEC , WZSTC |
| Model Number : | STIN-63 |
| Certification : | CE |
| Supply Ability : | 3000pcs/day |
| Delivery Time : | 15days |
Residual Current Circuit Breaker(FIN type)
Construction and Feature
Provides protection against earth fault/leakage current and
function of isolation.
High short-circuit current withstand capacity
Equipped with finger protected connection terminals
Resin parts endures abnormal heating and strong impact
Automatically disconnect the circuit when earth fault/leakage
current occurs and exceeds the rated sensitivity.
Independent of power supply and line voltage, and free from
external interference, voltage fluctuation.
Technical Data
=Model: Electro-magnetic type,electronic type
Residual current characteristics: A,AC
Pole NO.: 2,4
Rated current(A): 16,25,40,63
Rated voltage: 240/415V AC
Rated frequency: 50/60Hz
Rated residual operating current I n(A): 0.03,0.1,0.3,0.5
Rated residual non operating current Ino: 0.5In
Rated conditional short-circuit current Inc: 6kA
Rated conditional residual short-circuit Current I c: 6kA
Tripping duration:instantaneous tripping 0.1s
Residual tripping current range: 0.5In~In
Electro-mechanical endurance: 4000 cycles
Connection capacity: Rigid conductor 25mm2
Connection terminal:
Screw terminal
Pillar terminal with clamp
Fastening torque:2.0Nm
Installation:
On symmetrical DIN rail 35mm
Panel mounting
|
|
