| Brand Name : | SONTUOEC |
| Model Number : | STRO6-63LE |
| Certification : | CE |
| Price : | Negotiable |
| Supply Ability : | 5000PCS/DAY |
| Delivery Time : | 20DAYS |
STRO6-63LE residual current circuit breaker is in conformity with the standards of IEC61009.It can cut off the fault circuit immediately on the occasion of shock hazard or earth leakage of trunkline.Thus it is suitable to avoid the shock hazard and fire caused by earth leakage It can be used in circuits up to single phase 230V,three phase 400V,50 or 60Hz.It has the function of over-load current and short circuit protection. It also can 4Pole protection as Customers' request.
| Model | Electronic type/magnetic type |
| Residual Current characterstics | A,AC |
| Pole No | 1P+N,3P+N |
| Rated Current(A) | 6,10,16,20,25,32,40,63A |
| Rated Voltage(V) | 230/400V |
| Rated residual operating current | 10ma,30ma,100ma,300ma,500ma |
| Rated conditional residual short circuit current | 6KA |
| Electro-machanical endurance | over 4000 cycles |
