Voltage Circuit Breaker 10KA High Breaking Capacity up 100A IEC60947.2 110V, 240V MCB
General
STQC series high breaking capacity mini circuit breaker is used in
AC50/60Hz, rated voltage of 240V
1,2 poles 415V, rated current to 60A for overload and short-circuit
protection as well as for unfrequented switching under normal
case.It is used extensively for industry, commercial and
household.This product conform to IEC60898 standard.
The earthing systems,short-circuit current at the circuit breaker installation point,which must always be less than the breaking capacity of this device,network normal voltage.
B curve (3-5In) protection and control of the circuits against length cables in TN and IT systems.
C curve (5-10In) protection and control of the circuits against overloads and short-circuits; protection for resistive and inductive loads with low inrush current.
D curve (10-14In) protection and control of the circuits against overloads and short-circuits; protection for circuits which supply loads with high inrush current at the circuit closing (LV/LV transformers,breakdown lamps.)
Specifications
| Model | STQC MCB |
| Pole | 1P,2P,3P,4P |
| Rated Current(In) | 15,20,30,40,50,60,75,100,125A |
| Rated Voltage(Un) | 110/220V; 240/415V |
| Rated Frequency | 50/60HZ |
| Breaking capacity | 10KA(1P 120V); 5KA(240/415V) |
| Magnetic releases | |
| between 10 and 14In | |
| Electro-mechanical endurance | over 6000 cycles |
