Sontuoec 6KA RCCB Circuit Breaker 2P 400V AC 16A Electrical Type

Credit Suppliers SONTUOEC ID Series RCD RCCB 6KA Residual Current Circuit Breaker competitive price

General Introduction

Function

STID1-63 series RCCB(without overcurrent protection)applies to AC 50Hz, rated voltage 240V 2 poles, 415V 4 poles, rated current up to 63A. When electric shock occurs to human or leakage current in grid exceeds stipulated values, RCCB cuts off the fault power in a very short time to protect the safety of human and electrical equipments. It can also function as non frequently switching of circuits.

Main parameters

Sontuoec 6KA RCCB Circuit Breaker 2P 400V AC 16A Electrical Type

Standard: EN/IEC61008-1

Sontuoec 6KA RCCB Circuit Breaker 2P 400V AC 16A Electrical Type

Technical Data

Model: Electro-magnetic type; Electronic type
Residual current characteristics: A, AC
Pole No.: 2P, 4P
Rated making and breaking capacity: 630A
Rated current: 16A, 25A, 32A, 40A, 63A; 80A, 100A
Rated voltage: 230/400V AC
Rated frequency: 50/60Hz
Rated Residual Operating Current IΔn: 30mA, 100mA, 300mA, 500mA
Rated Residual Non-operating Current I Δno: ≤0.5IΔn
Rated conditional short-circuit current Inc: 6000A
Rated conditional residual short-circuit current IΔc: 6000A
Tripping duration: Instantaneous tripping ≤0.1Sec
Residual tripping current range: 0.5IΔn~IΔn
Electro-mechanical endurance: 4000 Cycles
Fastening torque: 2.0Nm
Connection terminal:
Screw terminal
Pillar terminal with clamp

Installation:
35mm Din rail mounting
Panel mounting
Model: A ; Ac ;
Type: Electronic type; Magnetic type
Our Services:
Competitive price
Continuance Service and support
Good-after service
Quality Reliability and Long Product Life.
