| Brand Name : | SONTUOEC, WZSTEC |
| Model Number : | L-DX2 |
| Certification : | CE |
| Price : | Negotiable |
| Supply Ability : | 5000PCS/DAY |
| Delivery Time : | 25DAYS |
SONTUOEC RCCB More than 20years profession manufacturer circuit
breaker MCB,RCCB, RCD, ELCB, RCBO, MCCB, ACB in China
L-DX2 series RCCB earth leakage circuit breaker is suitable to the circuit of AC50/60Hz.rated voltage 230V for 2 poles and 400V for 4 poles, and rated current up to 63A.when people come across the electric shock or the leakage current of the electrical network exceeds the fixed value, this product can cut off the fault current in short period so as to protect person and the equipments, It also can be used in the infrequent starting of the circuit and motors.
The circuit breaker is suitable to industry, commerce, high-rise building, household and other kinds
of places.
This product meets the standard of IEC/EN61008-1.
It has the following features:
In complicance with IEC/EN61008-1
Bilateral busbar wiring capabilities to adapt to the wider use of premises.
With functions of fault indicator.
Maximum connecting ability of 25mm2,wiring torque 3N *m, applicable to a variety of installing equipments,
wiring stronger.
Protection class:IP20
Specifications
| Model | Electronic type / magnetic type |
| Residual Current characteristics | A, AC |
| Pole NO | 2P/4P |
| Rated Current (A) | 16A,20A,25A,40A,63A |
| Rated Voltage (V) | 230/ 400V |
| Rated Residual operating current | 10mA ,30 mA , 100mA ,300mA ,500mA |
| Rated conditional resdual short circuit current | 6KA |
| Electro-machanical endurance | over 4000 cycles |
