40A / 30mA 4P Type A or AC RCBO with Overcurrent Protection Circuit Breaker :

Product Description:

The Product serves in the line of AC 50Hz,rated voltage 230V and rated current up to 40A to automatically and immediately cut off power supply once someone suffers from electric shock or leakage current above specified value.

It can effectively protect personal security and avoid the damage to equipments.

Circuit breaker is a kind of switching device which can turn on, load and break the current in normal circuit and can turn on, load and break the current in abnormal circuit within a specified time.

The SONTUOEC circuit-breaker can also function as overload and short-circuit protection and unfrequent changeover of line under normal condition.
The product is conformity with GB16917.1,IEC61009-1 Standards.

Sandard			IEC/EN61009.1
Electrical features	Type(wave form of the earth leakage sensed)		Electro-magnetic type, electronic type
	Rated current In	A	A,AC
	Poles	P	2,4
	Rated voltage	V	AC 240/415
	Rated Current :		6,10,16,20,25,32,40A
	Rated sensitivity I△n	A	0.01,0.03,0.1,0.3,0.5
	Insulation voltage Ui	V	500
	Rated residual making and breaking capacity I△m	A	630
	Short-circuit current I△c	A	6000
	SCPD fuse	A	6000
	Rated frequency	Hz	50/60
	Pollution degree		2
Mechanical features	Electrical life	t	4000
	Mechanical life	t	10000
	Protection degree		IP20
	Ambient temperature (with daily average ≤35℃)	℃	-25~+40
	Storage temperature	℃	-25~+70
Installation	Terminal connection type		Cable/U-type busbar/pin-type busbar
	Terminal size top/bottom for cable	mm2	25
		AWG	18-3
	Terminal size top/bottom for busbar	mm2	25
		AWG	18-3
	Tightening torque	N*m	2.5
		In-lbs	22
	Mounting		On DIN rail EN 60715(35mm)by means of fast clip device
	Connection		From top and bottom

Feature:

1. Without auxiliary power supply,the product is designed with strong immunity and extending protection range against residual current.
2. With higher rated ultimate short circuit,up to 6KA.
3. Reliable,accurate and convenient adjustment of product instantaneous action is ensured.
4. Service life of this SONTUOEC product has been greatly enhanced through specially designed tripping mechanism.
