| Brand Name : | SONTUOEC |
| Model Number : | STRO-40 |
| Certification : | CE,CB, SAA, ISO9001 |
| Price : | Negotiable |
| Supply Ability : | 3000PCS/DAYS |
| Delivery Time : | 15DAYS |
STPN05-40 residual current circuit breaker with overload current
protection is in conformity with the standards of IEC61009.also
comply with Australia ESV new standard ; It can cut off the fault
circuit immediately on the occasion of shock hazard or earth
leakage of trunkline.Thus it is suitable to avoid the shock hazard
and fire caused by earth leakage.It can be used in circuits up to
single phase 240V,three phase 415V,50 or 60Hz.
Product Over View:
1. Provide protection against earth fault/leakage current and function of isolation
2. High short-circuit current withstand capacity
3. Applicable to terminal and pin/fork type busbar connection
4. Equipped with finger protected connection terminals
5. Automatically disconnect the circuit when earth fault/leakage current occurs and exceeds the rated sensitivity
6. Independent of power supply and line voltage, and free from external interference, voltage fluctuation.
| Sandard | IEC/EN61009 | ||
| Electrical features | Type(wave form of the earth leakage sensed) | electronic type | |
| Rated current In | A | A,AC | |
| Poles | P | 1P+N | |
| Rated voltage | V | AC 230V | |
| Rated Current : | 10,16,20,25,32,40A | ||
| Rated sensitivity I△n | A | 0.01,0.03,0.1,0.3,0.5 | |
| Insulation voltage Ui | V | 500 | |
| Rated residual making and breaking capacity I△m | A | 630 | |
| Short-circuit current I△c | A | 4500 | |
| SCPD fuse | A |
| |
| Rated frequency | Hz | 50/60 | |
| Pollution degree | 2 | ||
| Mechanical features | Electrical life | t | 4000 |
| Mechanical life | t | 10000 | |
| Protection degree | IP20 | ||
| Ambient temperature (with daily average ≤35℃) | ℃ | -25~+40 | |
| Storage temperature | ℃ | -25~+70 | |
| Installation | Terminal connection type | Cable/U-type busbar/pin-type busbar | |
| Terminal size top/bottom for cable | mm2 | 25 | |
| AWG | 18-3 | ||
| Terminal size top/bottom for busbar | mm2 | 25 | |
| AWG | 18-3 | ||
| Tightening torque | N*m | 2.5 | |
| In-lbs | 22 | ||
| Mounting | On DIN rail EN 60715(35mm)by means of fast clip device | ||
| Connection | From top and bottom | ||
